Description
The SN74HC02N is a high-speed CMOS logic IC that includes four independent 2 input NOR gates in a standard DIP14 through hole package.
Each gate performs the Boolean function Y = A + B in positive logic, making it ideal for digital logic designs.
With low power consumption, buffered inputs, and support for wide operating voltages, it’s a drop in replacement for LSTTL logic ICs with improved performance and efficiency.
- Logic Type: Quadruple 2 Input NOR Gates (4 gates per IC)
- IC Model: SN74HC02N
- Package: DIP14 – Through Hole
- Input Type: Buffered CMOS
- Voltage Range: 2V to 6V
- Fan-Out: Up to 10 LSTTL Loads
- Temperature Range: –40°C to +85°C
- Power Efficient: Lower power consumption vs. traditional LSTTL ICs
- Pin Spacing: Standard 2.54mm (0.1″) – Breadboard & Perfboard Friendly
- Quantity: 5 ICs per pack
What’s Included:
- 5 x SN74HC02N DIP14 Quad 2-Input NOR Gate ICs
Great For:
- Digital Logic & Boolean Circuit Design
- Arduino, FPGA, and Microcontroller Interfacing
- Logic Education & Training Kits
- DIY Electronics & Breadboarding
- Logic Gate Expansion in Embedded Systems
Usage Tips:
- Suitable for both educational and commercial logic circuit projects
- Use with a 2V to 6V supply for optimal performance
- Ideal for soldering into PCBs or prototyping on breadboards
- Combine with other 74HC-series ICs for complex logic implementations
