Description
The NE556 SOP14 surface mount IC combines two independent 555 timer circuits in a single 14 pin package.
Perfect for generating precise timing intervals in monostable or astable modes, this versatile dual timer IC is ideal for a wide range of timing, pulse generation, and oscillator applications.
Designed for surface mount PCB assembly, the NE556 offers robust timing control with TTL-compatible outputs capable of sourcing or sinking up to 150mA.
- Type: Dual Precision Timer IC (Two 555 Timers)
- Part Number: NE556
- Package: SOP14 Surface Mount
- Supply Voltage: 4.5V to 16V
- Timing Circuits: Two independent per package
- Modes: Astable (oscillator) or Monostable (one-shot) operation
- Output: TTL-compatible, can source or sink up to 150mA
- Control: External resistor-capacitor (RC) timing with control-voltage modulation
- Additional Features: Active pullup or pulldown for stable output switching
What’s Included:
- 5 x NE556 SOP14 Dual Timer ICs (Surface Mount)
Great For:
- Timing and Pulse Generation Circuits
- Oscillator and Pulse Width Modulation (PWM)
- LED Flashers and Blinkers
- Delay Timers and Signal Generators
- DIY Electronics and PCB Prototyping
Usage Tips:
- Use external RC components to set timing intervals precisely
- Suitable for surface mount PCB designs and modern manufacturing
- TTL-compatible outputs simplify digital interfacing
- Ensure correct orientation during soldering for reliable operation
