Description
The SN74HC00N is a DIP14 through hole IC 4 independent 2-input NAND gates.
It performs the Boolean function Y = (A • B) or Y = A + B in positive logic, ideal for digital logic circuits, timing, and control applications.
Perfect for Arduino, Raspberry Pi, and general-purpose digital electronics projects.
- Product: SN74HC00N Quad 2-Input NAND Gate IC
- Type: DIP14 Through Hole
- Quantity: Pack of 2 ICs
- Contains four independent 2-input NAND gates
- Supply voltage range: 2V to 6V
- Output current: 5.2mA typical
- Low power consumption: 20µA max ICC
- Outputs can drive up to 10 LSTTL loads
- Typical propagation delay: 8ns
- Low input current: 1µA max
- 14-pin DIP package for easy prototyping and soldering
- Suitable for logic, timing, and switching circuits
What’s Included:
- 2 x SN74HC00N Quad 2-Input NAND Gate ICs
Great For:
- Building digital logic circuits and logic gate experiments
- DIY electronics, robotics, and automation projects
- Extending Arduino and microcontroller digital logic capabilities
- Educational and prototyping use
- General-purpose switching and timing applications
Usage Tips:
- Operate within 2V to 6V power supply range for best performance
- Use with common digital IC families like 74HC, 74LS, etc.
- Refer to datasheet for pinout and timing diagrams
- Ideal for breadboard and PCB through-hole assembly
